Resonance Atlas

Inkscape · Three vector posters and a film assembled from actual layers

A three-poster acoustic vector series in deep blue, cream and purple

Creative goal

Use original vector artwork to verify real Inkscape layer creation, curves, fonts, PDF, text outlining and save/reopen, then show the production layers through actual outputs.

31 phase trajectories, 48 dual-source wavefronts and 42 harmonic lines share a grid and editorial typography. Includes a 12-second silent assembly film.

Models and versions

Production, post-production and review are attributed separately. Unknown means records are insufficient; it does not mean the current model produced the work.

planning: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
creation: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
code: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
reference: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
post_production: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
review_visual: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.
review_technical: unknown · Reasoning effort:unknown
No independently checked backend configuration receipt.
This production stage.

Version history

v1 · 2026-10-11
Original native vector creation and assembly film; proportional detail crop verified.

English translation. Read the original Chinese text. Source evidence, downloads and native artwork retain their original language.

Prompt

Reusable prompt template

Use real Inkscape DCC-MCP to make three original illustrative acoustic posters. Use layers, curves and editorial typography; save and reopen natively, then export SVG, PNG, PDF and outlined SVG. Assemble an approximately 12-second film from actual PNGs and clearly distinguish it from a screen recording. Review at low resolution before final output. Never use AI images to fabricate software operations.

Reusable instructions, not the user's verbatim wording.

Software and tools

Host: Inkscape 1.4.4 / Ubuntu 24.04 / CI-owned Xvfb
Adapter: 0.1.0 source 498982a; unmerged PR #3 dependency
Core / CLI / Gateway: 0.20.42
Output: 1587×2116 PNG; native SVG/PDF; 1280×720 / 24fps / 12s silent video
Post-production: FFmpeg 7.1.5 / Pillow 12.3.0

inkscape_vector__document_build
Nine typed-plan sets created vectors through the software's native inkex effect.
inkscape_vector__document_inspect
Native reopen queries, including text=0 after outlining.
inkscape_vector__document_export
Native PNG, PDF and outlined SVG exports.
Pillow / FFmpeg
Aspect-ratio-preserving detail views and three-stage assembly of actual PNGs; not native Inkscape animation.

Refer to project documentation for installation, compatibility and current capabilities. This case's actual environment and execution evidence are recorded above.

Step-by-step process

Native plans
Nine typed-plan sets across three themes, created through the real gateway rather than an external XML writer.
Save and recheck
Reopened each set natively, exported PNG/PDF and reopened again after outlining. DejaVu font-embedding checks passed.
Assemble actual imagery
After low-resolution review, added large detail close-ups and corrected framing proportions, retaining full posters and the final triptych.

Results

1280 × 720, 24 fps, 12 seconds; silent; assembled from native PNGs, not a screen recording.

Phase / locked — JPEG display derivative of a native Inkscape PNG · 1587 × 2116; the complete lossless PNG is supplied separately

Between / waves — JPEG display derivative of a native Inkscape PNG · 1587 × 2116; the complete lossless PNG is supplied separately

After / sound — JPEG display derivative of a native Inkscape PNG · 1587 × 2116; the complete lossless PNG is supplied separately

Verification and boundaries

Check records; each row distinguishes historical measurements from this review.
Check	Result	Observations and supporting evidence
Native creation / save and reopen	Passed	55 real gateway calls; all nine sets passed native creation, export and reopening.
Fonts and outlines	Passed	DejaVu Sans/Bold embedded in PDF; outlined SVGs contain no text elements; extracted PDF text was checked.
Pixels and film	Passed	All three posters were reviewed individually; all 288 film frames decoded successfully.
GUI / final user acceptance	not_run	No GUI interaction recording or final user acceptance is claimed.

Evidence limits

The acoustic curves are mathematical illustrations, not measured data or pressure-field simulations.
The film is intentionally silent and has no audio track; it is composited from PNGs, not native Inkscape animation or a software screen recording.
Depends on an unmerged Linux native-fix commit; this does not establish support in an official release.
Public evidence is a redacted summary, not the complete original trace.

Last reviewed: 2026-10-11

Project files

Choose a project, reproduction package or exported resource. Before use, review this case's software versions, dependencies, format boundaries and rights.

Original lossless PNG exportsZIP · 3.8 MiB
Download project

Resources and rights

Source:Source and code
Source commit:498982ae7d4eedefeff31811c251795f5ff93be6

Author：DCC-MCP Resonance Atlas showcase contributors
License scope：Original artwork, video and new scripts: rights reserved; no additional MIT grant. Existing repository and third-party licenses unchanged.
No third-party images, AI-generated bitmaps or audio tracks.
