DCC-MCP Core Wordmark · C-Curve Correction

Preserves the interwoven letters, pixel starting point, and protocol connections while correcting the curve joins of both Cs; includes verified light and dark theme vectors and actual-size exports.

Asset version: v2 · Core wordmark

Corrected DCC-MCP core wordmark · Dark background · Actual 1024-pixel export

Verified assets · Verifiable files

Small-size previews

Two actual 128-pixel exports are shown at their native size to help inspect the small-size contours and text; both light and dark versions are visible together.

Corrected DCC-MCP core wordmark · Light background · Actual 128-pixel export
Light background · 128 × 57 px · Native size
Corrected DCC-MCP core wordmark · Dark background · Actual 128-pixel export
Dark background · 128 × 57 px · Native size

Asset downloads

Dimensions, file hashes, and applicable licenses are retained for each variant separately. Viewing this page does not automatically download source files.

English translation. Read the original Chinese text. Source evidence, downloads and native artwork retain their original language.

Prompt

Reusable prompt
Use DCC-MCP's native Inkscape vector tools to correct both Cs in the DCC-MCP core wordmark. Preserve the 900 × 400 canvas, D's interwoven tail, pixel starting point, protocol connections, and MCP typography. Make the C1 curve joins G1-continuous while retaining the nonuniform-thickness contour and flat angled end faces; use concentric arcs for C2 with an outer radius of 100, inner radius of 63, and radial thickness of 37, retaining straight radial end faces. Build separate editable SVGs for the light and dark themes, and use the actual software to export SVGs with text converted to outlines, plus transparent 1024 × 455 and 128 × 57 PNGs. Record every MCP request and response, output hashes, geometry checks, and actual pixel checks; do not mark other families that have not yet been produced as complete.

A reusable prompt prepared from this round's production goals, rather than a verbatim original user prompt. The actual build plans and export parameters are retained in the public MCP records.

Production tools and versions

Inkscape
Inkscape 1.4.4
DCC-MCP adapter · Actual production for this entry
commit 7657bafe78dad0c59c833e25da6f330067c2e64b; commit fd5a71d4a59349f34b044aeec6244523137c3453. Per-output commits are retained in the production records; the current public draft commit is listed separately and does not imply that historical files were rerun on the current version.
DCC-MCP Core
0.20.36
DCC-MCP Gateway / CLI
0.20.38
  • inkscape_vector__document_build

    Build editable documents, curves, and layers through native vector plans.

  • inkscape_vector__document_export

    Export transparent PNGs and SVGs with text converted to outlines using the actual Inkscape software.

Step-by-step process

  1. Preserve the layout and correct both Cs

    Save light and dark native SVGs using actual vector build plans. Visual records confirm that only the properties of dcc-c1 and dcc-c2 changed, while the rest of the graphic layout was preserved.

  2. Export PNGs in both themes

    Export transparent 1024 × 455 and 128 × 57 PNGs in the actual Inkscape software. The image below is the final light-theme result and is not evidence of an intermediate state.

    Corrected DCC-MCP core wordmark · Light background · Actual 1024-pixel export
    Corrected DCC-MCP core wordmark · Light background · Actual 1024-pixel export
  3. Retain editable and outlined versions

    Native SVGs retain editable Montserrat text; the actual software separately exports release SVGs with text converted to paths. Font files are not distributed with this work, and separate OFL notes are provided.

  4. Verify geometry and actual small-size outputs

    Read the saved paths and actual PNGs to check curve joins, concentric circles, and end faces; inspect readability on light and dark backgrounds using actual 128-pixel exports. Visual quality checks are complete, while the overall design still awaits user review.

    Corrected DCC-MCP core wordmark · Dark background · Actual 1024-pixel export
    Corrected DCC-MCP core wordmark · Dark background · Actual 1024-pixel export
  5. Complete the core currentColor versions

    After the native route was fixed, separate actual requests built versions with editable text and text paths, followed by a software-exported currentColor release SVG. The older light and dark outputs were not relabeled as reruns on a new version.

Verification and evidence limits

Actual verification records; the scope of the evidence is limited to the observations in each entry.
CheckResultObservations and supporting evidence
Actual finished outputs and production receiptsPassedThe byte counts and SHA-256 hashes of the 11 core outputs match the original manifest, corresponding successful Gateway responses, and export receipts. Each file retains its actual production commit.
C1 curve joinsPassedThe maximum tangent-angle change at internal joins is 1.89169726e-06°, satisfying G1 within numerical rounding; neither G2 continuity nor uniform thickness for C1 is claimed.
C2 concentric circles and thicknessPassedOuter/inner radii are 100 / 63, with a radial thickness of 37; the recovered center deviation is 1.10607051e-06 design pixels.
Scope of changesPassedOnly the properties of both Cs changed in the light and dark native documents; all other native graphic properties were preserved.
Actual 128-pixel exportsPassedBoth actual 128 × 57 PNGs have been viewed on their corresponding backgrounds; the letters are distinguishable, while separation between the thin protocol lines and nodes is reduced at this size.
Transparent PNGs and SVG rolesPassedAll four light and dark PNGs pass transparent-corner checks; three SVGs retain text, while the other four SVGs contain text paths. Editable-text and outlined files are provided separately according to their actual roles.
DCC rerun during this site integrationNot runThe production task has separate native inspect records; this site's integration reads and verifies existing finished outputs. Public records retain the corresponding output calls and do not claim that the site reran software production.
GUI visual acceptance reviewUnverifiedProduction records show that the corrected light-theme master was reopened and part of the canvas was observed; at 162% zoom, the right-hand hexagon was clipped, so a complete-page GUI acceptance review remains unfinished. This record does not cover interface acceptance review of the newly added currentColor documents.
User design reviewNot runGeometry and pixel checks are complete; design acceptance awaits user review.
Three core currentColor SVGsPassedThe native version retaining text, the outlined native version, and the software-exported release SVG have all been checked against actual successful calls and file QA. The font dependency applies only to the version retaining text.

Evidence limits

  • Actual files exist for the core light, dark, and currentColor themes; refer to the single production manifest for the completion status of other sizes and the full family plan.
  • Website integration checks existing finished outputs and records; it did not rerun Inkscape production.
  • Public requests retain vector plans and hashes while removing private paths, hosts, instance identifiers, and service connection parameters.
  • Part of the canvas has been observed in the core native GUI; the complete page was not successfully fitted into view, so no claim is made that a complete GUI acceptance review passed.
  • Geometry and pixel verification are recorded separately from the user's design acceptance; user review remains pending.
  • This is a vector reconstruction and correction based on the reference layout, with no claim that the original logo source files were recovered or that the result is pixel-identical.
  • C1 uses G1 joins and retains its nonuniform-thickness design; G2 continuity is not claimed.
  • The before-and-after comparison contains reference images whose public-use licenses have not been confirmed, so it is excluded from public downloads.
